    Notice: Launch Schedule Update

    To ensure the best possible printing experience and product quality, we are currently performing final optimizations and additional testing on the Photon P1 Max. As a result, the official launch originally planned for March 16 will be rescheduled to Mid-May. We truly appreciate your patience and support. The extra time will allow us to deliver a product that meets the highest standards our users expect.

    Thank you for your understanding, and stay tuned for the official launch!

    Photon P1 Max Exclusive Bonuses

    Photon Series Tech Specs

    Name Photon P1 Max Photon P1 Photon Mono M7 Max
    Product Image
    Printing Precision 14" 12K 10.1" 14K 13.6" 7K
    Printing Size 285.5 × 214 × 300 mm³ 223 × 126 × 230 mm³ 298 × 164 × 300 mm³
    Build Volume 18.3L 6.5L 14.7L
    XY Precision 24.8μm × 24.8μm 16.8μm × 24.8μm 46μm × 46μm
    Light Source COB + Fresnel + Mask COB + Fresnel + Mask COB + Fresnel
    Leveling Auto-Leveling 3.0 (with leveling feedback) Auto-Leveling 3.0 (with leveling feedback) Manual leveling (4-point adjustment)
    Z-Axis Drive C7 Ball screws‌ C7 Ball screws‌ T-screws
    Resin Vat Capacity 1900ml 1000ml 1300ml
    Remote Control APP + Camera monitoring APP + Camera monitoring APP + Camera monitoring

    FAQs

    Q1: How large can I print with the Photon P1 Max?

    A: The Photon P1 Max offers a massive 18.3L full-scale build volume, allowing you to produce large models or maximize batch production in a single print cycle. Combined with its 1.9L thermal-controlled resin vat, it supports models up to 300mm tall while maintaining consistent resin viscosity for higher success rates and improved productivity.

    Q2: How does the Photon P1 Max achieve silky-smooth, ultra-detailed prints?

    A: Equipped with a 14-inch 12K screen (11520 × 8640 px) and 24.8 × 24.8 μm square pixels, the P1 Max eliminates jagged edges and visible layer artifacts.

    Q3: What ensures long-term precision and mechanical stability in the Photon P1 Max?

    A: The Photon P1 Max utilizes C7-grade ball screws and linear guide rails, achieving an impressive repeat positioning accuracy of ±0.01 mm. This robust motion control system provides a rock-solid foundation, ensuring stable operation and print precision.

    Q4: How does the Photon P1 Max improve print consistency and success rate?

    A: The Photon P1 Max uses LightTurbo 4.0 technology to deliver highly reliable prints:

    • More Light Precision: Aspherical Fresnel Lens:‌ ≤3° collimation accuracy
    • More Uniform Light Distribution: Full-screen Rolling Calibration:‌ >92% illumination uniformity (208-point measurement)
    • More Stable Light Output: 8mm Copper Cooling System:‌ Minimum light decay, maximum light source lifespan

    Q5: What features make the Photon P1 Max easy to use?

    A: With dual-network connectivity (Wi-Fi + Ethernet), remote monitoring via the Anycubic App, and compatibility with ultra-viscous 8000cps resins, the Photon P1 Max delivers a seamless, intelligent, and production-ready experience.

    • Factory calibration — Ready to print out of the box
    • Auto-Leveling Self-Check — Automatically performs bed leveling self-check before printing to ensure optimal platform readiness.
    • Leveling-Assist — Displays real-time force values at four corners for
      fine-tuning.

    Q6: What are the 5 Exclusive Bonuses of Photon P1 Max?

    A: When purchasing the Photon P1 Max, you can enjoy the following 5 Exclusive Bonuses. These exclusive offers are designed to lower both your upfront investment and long-term printing costs:

    • 3KG Resin from $74.99 (*Included in Bundles)
    • 50% OFF on Photon P1 Max Related Accessories.
      Material Subsidy: Save $16 on 10KG Resin / Save $8 on 5KG Resin       (*Customers who purchase the Photon P1 Max during the Early Bird or Pre-Sale stage will receive exclusive discounts on resin purchases. The discount will be automatically applied to your next resin purchase.)
    • Save up to $160 with Wash & Cure Bundles: Bundle your printer with Wash & Cure units to maximize savings.
    • Buy 2 Units, Save $160: Purchase two Photon P1 Max units and receive an additional $160 discount.
