Anycubic Resin User Manual

Please select and click it to preview or download.


Standard Resin

Standard Resin V2

Standard Resin+

Water-Wash Resin+

Water-Wash Resin 2.0

ABS-Like Resin+

ABS-Like Resin Pro 2

ABS-Like Resin 3.0

ABS-Like Resin V2

DLP Craftsman Resin

14K Texture Resin

Plant-Based Resin 2.0

UV Tough Resin

Tough Resin 2.0

Tough Resin Ultra

High Clear Resin

High Speed Resin 2.0

Bio Resin

DIY Color Mixing Resin

UV Resin MSDS

Standard Resin

Download MSDS_EN

Plant-based UV Resin

Download MSDS_EN

Tough Resin 2.0

Download SDS_EN

DLP Craftsman Resin

Download SDS_EN

Water-Wash Resin+

Download SDS_EN

ABS-Like Resin Pro 2

Download SDS_EN

High Clear Resin

Download SDS_EN

High Speed Resin 2.0

Download SDS_EN

ABS-Like Resin V2

Download SDS_EN

Standard Resin V2

Download SDS_EN

Tough Resin Ultra

Download SDS_EN

Bio Resin

Download SDS_EN

Rigid 100 Resin

Download SDS_EN

Texture Resin

Download SDS_EN

DIY Color Mixing Resin

Download SDS_EN

Water-Wash 2.0

Download SDS_EN

ABS-Like Resin 3.0

Download SDS_EN

Filaments SDS

PLA

Download MSDS_EN

PLA High Speed

Download MSDS_EN

PLA+

Download MSDS_EN

PLA Silk

Download MSDS_EN

PLA Metal

Download MSDS_EN

PETG

Download MSDS_EN

PLA Matte

Download MSDS_EN

PLA Glow

Download MSDS_EN

ABS

Download MSDS_EN

TPU

Download MSDS_EN

ASA

Download MSDS_EN

Standard Resin Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 2 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.1 mm 2.2 s 0.5 s 25 s 3 1 4 mm 15 mm/s 15 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 0.5 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 0.5 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 2.6 s 1 s 30 s 5 1 5 mm 8 mm/s 8 mm/s
Photon Mono 4 0.05 mm 2.8 s 1 s 30 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 2.8 s 0.5 s 25 s 5 1 5 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20 s 5 1 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 2 s 0.5 s 23 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2.5 s 50 s 6 1 10 mm 2 mm/s 3 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 20 s 5 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 0.5 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

Standard Resin V2 Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 2 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.1 mm 2.2 s 0.5 s 25 s 3 1 4 mm 15 mm/s 15 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 0.5 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 0.5 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 2.6 s 1 s 30 s 5 1 5 mm 8 mm/s 8 mm/s
Photon Mono 4 0.05 mm 2.8 s 1 s 30 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.1mm 3s 0.5 s 25 s 6 1 5 mm 20 mm/s 20 mm/s
Photon Mono M5s 0.05 mm 2.8 s 0.5 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20 s 5 1 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 2 s 0.5 s 23 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2.5 s 50 s 6 1 10 mm 2 mm/s 3 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5 s 25 s 2 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 20 s 5 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 0.5 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

ABS-Like Resin Pro 2 Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 2 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 1 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 1 s 35 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 2.6 s 1 s 30 s 5 1 5 mm 8 mm/s 8 mm/s
Photon Mono 4 0.05 mm 2.8 s 1 s 30 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 1 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 3 s 0.5 s 25 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 6 1 8 mm 6 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20 s 6 1 8 mm 2 mm/s 3 mm/s
Photon Mono X 6K 0.05 mm 2 s 0.5 s 23 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2 s 30 s 6 1 10 mm 4 mm/s 4 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5 s 25 s 3 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 28 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 25 s 5 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 0.5 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

Water-Wash Resin 2.0 Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 2 s 0.5 s 30 s 5 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 0.5 s 25 s 4 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.5 s 1 s 35 s 4 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 2.6 s 1 s 30 s 5 5 mm 8 mm/s 8 mm/s
Photon Mono 4 0.05 mm 2.8 s 1 s 30 s 5 6 mm 4 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 0.5 s 30 s 5 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 2.8 s 0.5 s 25 s 5 8 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 5 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20 s 5 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 2 s 0.5 s 23 s 6 8 mm 2 mm/s 6 mm/s
Photon M3 Max 0.05 mm 3 s 2.5 s 35 s 6 10 mm 2 mm/s 3 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5 s 25 s 4 8 mm 6 mm/s 6 mm/s
Photon M3 Plus 0.05 mm 1.5 s 0.5 s 23 s 4 6 mm 6 mm/s 6 mm/s
Photon M3 0.05 mm 2 s 0.5 s 23 s 4 6 mm 3 mm/s 4 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 20 s 5 8 mm 2 mm/s 3 mm/s
Photon D2 0.05 mm 2.5 s 1 s 28 s 5 5 mm 2 mm/s 3 mm/s
Photon Mono SQ 0.05 mm 2.3 s 0.5 s 23 s 6 5 mm 3 mm/s 3 mm/s
Photon Mono SE 0.05 mm 1.5 s 0.5 s 30 s 6 6 mm 4 mm/s 6 mm/s
Photon Ultra 0.05 mm 2 s 1 s 35 s 4 5 mm 2 mm/s 2 mm/s
Photon Mono 4K 0.05 mm 2 s 0.5 s 40 s 6 6 mm 4 mm/s 6 mm/s
Photon Mono X 0.05 mm 2 s 0.5 s 28 s 4 8 mm 2 mm/s 6 mm/s
Photon Mono 0.05 mm 2.5 s 0.5 s 40 s 4 6 mm 4 mm/s 6 mm/s
Photon S 0.05 mm 9 s 1 s 60 s 6 6 mm 3 mm/s 3 mm/s

ABS-Like Resin 3.0 Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 3.2 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 1 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 1 s 35 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 2.6 s 1 s 30 s 5 1 5 mm 8 mm/s 8 mm/s
Photon Mono 4 0.05 mm 2.8 s 1 s 30 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 1 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 3 s 0.5 s 25 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 6 1 8 mm 6 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20 s 6 1 8 mm 2 mm/s 3 mm/s
Photon Mono X 6K 0.05 mm 2 s 0.5 s 23 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2 s 30 s 6 1 10 mm 4 mm/s 4 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5 s 25 s 3 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 28 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 25 s 5 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 0.5 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

High Speed Resin 2.0 Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Pro 0.01 mm 1.5 s 0.5 s 15 s 5 1 4 mm 15 mm/s 15 mm/s
Photon Mono M7 0.01 mm 1.4 s 0.5 s 15 s 5 1 4 mm 15 mm/s 15 mm/s
Photon Mono M5s Pro 0.01 mm 1.9 s 0.5 s 15 s 5 1 3 mm 20 mm/s 20 mm/s
Photon Mono M5s 0.01 mm 1.9 s 0.5 s 15 s 5 1 3 mm 20 mm/s 20 mm/s
Photon Mono M5 0.01 mm 2 s 0.5 s 15 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X6Ks 0.01 mm 2.5 s 0.5 s 15 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X 6K 0.01 mm 2 s 0.5 s 18 s 6 1 6 mm 4 mm/s 6 mm/s
Photon M3 Max 0.01 mm 2.8 s 0.5 s 25 s 6 1 8 mm 4 mm/s 4 mm/s
Photon M3 Premium 0.01 mm 2.5 s 0.5  s 25 s 5 1 6 mm 6 mm/s 6 mm/s
Photon Mono 2 0.01 mm 2.5 s 0.5 s 18 s 5 1 5 mm 4 mm/s 6 mm/s
Photon Mono X2 0.01 mm 2.5 s 0.5 s 18 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono 4K 0.01 mm 2 s 0.5  s 25 s 6 1 5 mm 4 mm/s 6 mm/s

High Clear Resin Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Pro 0.05 mm 4 s 0.5 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 4 s 1 s 35 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 4 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 4 s 0.5 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 4 s 0.5 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 4 s 0.5 s 20 s 5 1 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 4 s 0.5 s 28 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 4.5 s 2.5 s 30 s 6 1 10 mm 2 mm/s 3 mm/s
Photon M3 Premium 0.05 mm 4 s 0.5 s 25 s 3 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 4 s 1 s 25 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 4 s 0.5 s 25 s 5 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 4 s 0.5 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

Tough Resin 2.0 Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 2 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 2 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 1 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 1 s 1 s 30 s 5 1 5 mm 8 mm/s 8 mm/s
Photon Mono 4 0.05 mm 1 s 1 s 30 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 1 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.1 mm 3 s 1 s 25 s 6 1 5 mm 20 mm 20 mm
Photon Mono M5s 0.05 mm 2.8 s 1 s 25 s 6 1 8 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 1 s 25 s 6 1 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 1 s 20 s 6 1 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 2 s 1 s 28 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2 s 35 s 6 1 10 mm 2 mm/s 3 mm/s
Photon M3 Premium 0.05 mm 2.5 s 1  s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 1 s 20 s 5 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 1 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

14K Texture Resin Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 2 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 1 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 0.5 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 3 s 1 s 35 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono 4 0.05 mm 2.4 s 1 s 30 s 5 1 5 mm 8 mm/s 8 mm/s
Photon Mono M5s Pro 0.05 mm 3.2 s 1 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 2.8 s 1 s 30 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 1 s 30 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 1 s 20 s 5 1 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 2 s 1 s 30 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2 s 35 s 6 1 10 mm 4 mm/s 4 mm/s
Photon M3 Premium 0.05 mm 2.5 s 1  s 35 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 1 s 25 s 5 1 8 mm 4 mm/s 4 mm/s
Photon Mono 4K 0.05 mm 2 s 1 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

DIY Color Mixing Resin Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Pro 0.05 mm 2 s 0.5 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.5 s 1 s 35 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 3 s 1 s 35 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono 4 0.05 mm 2.4 s 1 s 30 s 5 1 5 mm 8 mm/s 8 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 0.5 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 2.8 s 0.5 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20 s 5 1 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 2 s 0.5 s 23 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2.5 s 35 s 6 1 10 mm 2 mm/s 3 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5  s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 20 s 5 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 0.5 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

Water-Wash ABS-like Resin V2 Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 2 s 0.5 s 30 s 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.05 mm 1.8 s 0.5 s 25 s 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.1 mm 3.6 s 0.5 s 35 s 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 1 s 35 s 1 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 2.6 s 1s 30 s 1 5 mm 8 mm/s 8 mm/s
Photon Mono 4 0.05 mm 2.8 s 1 s 30 s 1 6 mm 4 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 4.2 s 0.5 s 35 s 1 5 mm 20 mm/s 20 mm/s
Photon Mono M5s 0.05 mm 2.8 s 0.5 s 25 s 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.1 mm 3.2 s 0.5 s 25 s 1 5 mm 20 mm/s 20 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 1 8 mm 6 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20 s 1 8 mm 2 mm/s 3 mm/s
Photon Mono X 6K 0.05 mm 2 s 0.5 s 23 s 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2 s 30 s 1 10 mm 4 mm/s 4 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5  s 25 s 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 25 s 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 0.5 s 40 s 1 6 mm 4 mm/s 6 mm/s

DLP Craftsman Resin Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon M3 Premium 0.05 mm 2.5 s 0.5 s 25 s 2 1 8 mm 6 mm/s 6 mm/s
Photon M3 Max 0.05 mm 2 s 2.5  s 35 s 6 1 8 mm 3 mm/s 4 mm/s
Photon M3 Plus 0.05 mm 2 s 0.1 s 23 s 3 1 8 mm 2 mm/s 3 mm/s
Photon M3 0.05 mm 2 s 0.5 s 23 s 4 1 6 mm 3 mm/s 4 mm/s
Photon D2 0.05 mm 2.5 s 1 s 28 s 5 16 5 mm 2 mm/s 3 mm/s
Photon Ultra 0.05 mm 2 s 1 s 35 s 4 4 6 mm 5 mm/s 2 mm/s
Photon Mono X 6K 0.05 mm 2.5 s 0.5 s 40 s 8 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 0.5 s 40 s 6 1 6 mm 4 mm/s 6 mm/s
Photon Mono X 0.05 mm 2 s 0.5 s 30 s 8 1 8 mm 4 mm/s 4 mm/s
Photon Mono 0.05 mm 2.5 s 0.5 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

Plant-Based UV Resin 2.0 Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Max 0.05 mm 2 s 0.5 s 30 s 5 8 mm 6 mm/s 6 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 0.5 s 25 s 4 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.5 s 1 s 35 s 4 8 mm 6 mm/s 6 mm/s
Photon Mono 4 Ultra 0.05 mm 2.6 s 1 s 30 s 5 5 mm 8 mm/s 8 mm/s
Photon Mono 4 0.05 mm 2.8 s 1 s 30 s 5 6 mm 4 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 0.5 s 30 s 5 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.05 mm 2.8 s 0.5 s 25 s 5 8 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 0.5 s 25 s 5 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 0.5 s 20  s 5 8 mm 3 mm/s 4 mm/s
Photon M3 Premium 0.05 mm 2.5 s 0.5 s 25 s 4 8 mm 6 mm/s 6 mm/s
Photon M3 Max 0.05 mm 3 s 2.5  s 35 s 6 10 mm 2 mm/s 3 mm/s
Photon M3 Plus 0.05 mm 1.5 s 0.5 s 23 s 4 6 mm 6 mm/s 6 mm/s
Photon M3 0.05 mm 2 s 0.5 s 23 s 4 6 mm 3 mm/s 4 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 0.5 s 20 s 5 8 mm 2 mm/s 3 mm/s
Photon D2 0.05 mm 2.5 s 1  s 28 s 5 5 mm 2 mm/s 3 mm/s

Tough Resin Ultra Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Pro 0.05 mm 2 s 2 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 1 s 25 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.6 s 1 s 30 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s 0.1 mm 3 s 1 s 25 s 6 1 5 mm 20 mm/s 20 mm/s
Photon Mono M5s 0.05 mm 2.8 s 1 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono M5 0.05 mm 2.8 s 1 s 25 s 5 1 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 1 s 20 s 5 1 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 2 s 1 s 28 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2 s 35 s 6 1 10 mm 2 mm/s 3 mm/s
Photon M3 Premium 0.05 mm 2.5 s 1  s 25 s 2 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 5 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 1 s 20 s 5 1 8 mm 2 mm/s 3 mm/s
Photon Mono 4K 0.05 mm 2 s 1  s 40 s 6 1 6 mm 4 mm/s 3 mm/s

Bio Resin Ultra Recommended Printing Parameters

Printer Model Layer Thickness Exposure Time Light-Off Time Bottom Exposure Time Bottom Layers Anti-Aliasing Level Z Lift Distance Z Lift Speed Z Retract  Speed
Photon Mono M7 Pro 0.1 mm 2.2 s 2 s 35 s 4 1 4 mm 15 mm/s 15 mm/s
Photon Mono M7 Pro 0.05 mm 2 s 1 s 25 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono M7 0.05 mm 2.2 s 1 s 35 s 4 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s Pro 0.05 mm 3.2 s 1 s 35 s 6 1 8 mm 6 mm/s 6 mm/s
Photon Mono M5s Pro 0.1 mm 3.8 s 1 s 35 s 6 1 5 mm 20 mm/s 20 mm/s
Photon Mono M5s 0.05 mm 2.8 s 1 s 35 s 6 1 8 mm 5 mm/s 6 mm/s
Photon Mono M5s 0.1 mm 3 s 1 s 35 s 6 1 5 mm 20 mm/s 20 mm/s
Photon Mono M5 0.05 mm 2.8 s 1 s 35 s 6 1 8 mm 5 mm/s 6 mm/s
Photon Mono X6Ks 0.05 mm 2.5 s 1 s 20 s 6 1 8 mm 3 mm/s 4 mm/s
Photon Mono X 6K 0.05 mm 2 s 1 s 30 s 6 1 8 mm 2 mm/s 3 mm/s
Photon M3 Max 0.05 mm 3 s 2 s 35 s 6 1 10 mm 4 mm/s 4 mm/s
Photon M3 Premium 0.05 mm 2.5 s 1 s 35 s 5 1 8 mm 6 mm/s 6 mm/s
Photon Mono 2 0.05 mm 2.5 s 1 s 25 s 6 1 6 mm 4 mm/s 6 mm/s
Photon Mono X2 0.05 mm 2.5 s 1 s 25 s 5 1 8 mm 4 mm/s 4 mm/s
Photon Mono 4K 0.05 mm 2 s 1 s 40 s 6 1 6 mm 4 mm/s 6 mm/s

Explore More Materials

View all
